PP PE PVC Single Wall Corrugated Pipe Extrusion Line

Machine Features:

ü Material: PP/PE/PA/PVC

ü Pipe diameter range: up to 63mm

ü Max. Capacity: up to 200kg/h

ü Layers structure: Single Layer or Three Layers

Main Parts details of SWC Machine:

Siemens PLC Control System

ü Siemens PLC + HMI Control to assure the machine running precision and easy operation

ü Intelligent & centralized control

ü Automatic preheating

ü Remote monitoring

ü Intelligent alarm system

-------------------------------------------------------------------------------------------------------------------------------

High Efficient Extruder

ü Siemens PLC control system

ü Quality 38CrMoAl/Bimetallic screw and barrel material to assure long life using

ü Specified screw design for better material plasticizing

ü Control Panel: ABB/Siemens Inverter,Siemens low-voltage elements, Schneider breaker etc

ü Main motor: Siemens China

ü Reducer: Compact structure/High load capacity/High transmission efficiency/NSK or SKF Bearing/Oil temperature control

-------------------------------------------------------------------------------------------------------------------------------

Die head

ü Die head material: 40Cr

ü Surface treatment: Polishing and Chromed

ü Professional design to assure the stable pipe extruding and even wall thickness. We can get the quality pipe extruding with the least material wasting.

-------------------------------------------------------------------------------------------------------------------------------

Calibration blocks

ü Material: Casting 40Cr steel

ü Material treatment: Nitrided

ü Inner surface treatment: Polishing

ü Cooling method: by fan blower or Water

ü Processed: High precision CNC

ü The best design for calibration block in China.

ü Wear-resistance for high speed production.

-------------------------------------------------------------------------------------------------------------------------------

Fast Speed Calibration table - Block pushing style

ü Design: Block pushing type

ü Platform material: Wear-resistant Casting steel

ü Cooling method: Water cooling

ü Control: Siemens PLC

ü Advantage of our design:

Ø Faster speed

Ø More stable running

Ø High quality corrugated pipe forming

-------------------------------------------------------------------------------------------------------------------------------

Double position winder

ü Coiler qty: One or Two

ü Automatic lining

ü Pneumatic open and close

-------------------------------------------------------------------------------------------------------------------------------

Control Panel

ü PLC + touch screen control system: SIEMENS

ü Low voltage electrical parts: SIEMENS

ü Buttons: Schneider

ü Air switch: LG

ü Inverter: ABB or Siemens

ü DC speed regulator: Parker

ü Servo motor controller: Siemens

ü Pressure sensor: Gefron or Danisco
